From microphone to MP3: the Myousica audio pipeline

• myousica
• music
• ruby
• rails
• audio
• open-source

This is the third and final post in the Myousica series. The first covered the Rails platform, the second the Flash multitrack editor. This one covers how audio actually gets from the user’s microphone to a playable MP3 — the pipeline that connects all the services together.

The uploader is a separate Rails 2.2 application — headless, no database, no ActiveRecord. Just controllers, background workers, and audio processing tools. Andrea Franz built the initial version in April 2008, I took over from May 2008 onwards. 120 commits, originally called multitrack_server before being renamed to mewsic-uploader in March 2009.

The full pipeline¶

Here’s the complete flow from microphone to playable track:

Two entry points: the user can upload an MP3 file directly, or record via microphone (which produces an FLV stream through Red5). Both end up as an MP3 with a waveform PNG.

Stateless authentication¶

The uploader has no user sessions — session :off in the ApplicationController. Every request is authenticated by asking the main Myousica app whether the token is valid:

class ApplicationController < ActionController::Base
  before_filter :check_auth
  session :off

  def check_auth
    unless params[:id] && params[:token]
      redirect_to '/' and return
    end

    url = URI.parse "#{AUTH_SERVICE}/#{params[:id]}?token=#{params[:token]}"
    unless Net::HTTP.start(url.host, url.port) { |http|
      http.post(url.path, url.query)
    }.is_a?(Net::HTTPSuccess)
      redirect_to '/' and return
    end
  end
end

Every upload, every encode request, every mix request — they all carry ?id=USER_ID&token=TOKEN in the query string. The uploader POSTs to the main app’s /multitrack/_/:id endpoint and checks for HTTP 200. This is necessary because Flash uploads can’t carry cookie sessions — the token is the only way to authenticate.

The upload controller¶

When a file arrives, the controller copies it to a spool directory and dispatches a background worker:

class UploadController < ApplicationController
  def index
    @worker_key = random_md5

    input = input_file(random_md5) << '.mp3'
    FileUtils.cp params[:Filedata].path, input

    MiddleMan.worker(:ffmpeg_worker).async_run(
      :arg => {
        :key => @worker_key,
        :input => input,
        :output => random_output_file,
        :track_id => params[:track_id],
        :user_id => params[:id]
      })

    render_worker_status
  end
end

The response is immediate — an XML status document with a worker key. The Flash client polls /upload/status/:worker_key until the encoding is done. No long-running HTTP connections, no websockets. Just polling.

The random_md5 generates unique filenames from MD5.md5(rand.to_s). Collision-free enough for a music platform.

The encoding pipeline¶

The FfmpegWorker is a BackgrounDRb worker with a pool size of 3 — at most 3 tracks can be encoded simultaneously. The encode_to_mp3 method runs through four stages:

def encode_to_mp3(options)
  key, input, output = options[:key], options[:input], options[:output]
  update_status key, :running, output, 0

  # 1. Format conversion (FLV → WAV if needed)
  if input =~ /\.flv$/
    tempfile = Tempfile.new 'wavepass'
    Wavepass.new(input, tempfile.path).run
    input = tempfile.path
  end

  # 2. Volume analysis
  process = SoxAnalyzer.new(input, format).run
  optimum = process.optimum_volume

  # 3. Normalization
  tempfile = Tempfile.new 'normalizer'
  SoxNormalizer.new(input, tempfile.path, optimum, format).run
  input = tempfile.path

  # 4. MP3 encoding
  FFmpeg.new(input, output).run

  # 5. Waveform
  length = Mp3Info.new(output).length
  Adelao::Waveform.generate(input, output.sub('.mp3', '.png'), :width => length * 10)

  # 6. Callback
  update_mixable :path => TRACK_SERVICE, :filename => File.basename(output),
    :length => length, :track_id => options[:track_id], :user_id => options[:user_id]

  update_status key, :finished, output, length
ensure
  File.unlink input
  GC.start
end

Each stage shells out to an external tool via the Executable base class — a minimal wrapper around fork + exec:

class Executable
  def run
    unless @status
      Process.wait(fork { exec(self.to_cmd) })
      @status = $?.exitstatus
    end
    return self
  end

  def success?
    @status.zero?
  end
end

Simple. Fork a child process, exec the command, wait for it, check the exit code. No pipes, no shell interpretation, no surprises.

Audio analysis and normalization¶

The volume normalization is the most interesting part of the pipeline. Before encoding, sox analyzes the audio to find the optimal volume level:

class SoxAnalyzer < StdOutputter
  def to_cmd
    "sox -t %s %s -n stat -v" % [@format, @input]
  end

  def optimum_volume
    @output.to_f * 90 / 100
  end
end

The sox ... -n stat -v command outputs a single number: the volume multiplier that would bring the audio to maximum level without clipping. The SoxAnalyzer captures that number from stdout (via the StdOutputter subclass of Executable) and scales it to 90% — leaving 10% headroom to avoid distortion when tracks are mixed together.

Then the normalizer applies the computed volume:

class SoxNormalizer < Executable
  def to_cmd
    "sox -v %f -t %s %s -t wav %s" % [@volume, @format, @input, @output]
  end
end

This means every track in Myousica is volume-normalized before it’s made available. When you add someone’s guitar track to your mix, it’s at a consistent level — you don’t get one track blasting your ears while another is barely audible.

Multi-track mixing¶

The SoxWorker handles the final mixdown — taking multiple tracks and combining them into a single MP3. Each track can have a per-track volume adjustment (set by the user in the multitrack editor):

def mix_tracklist(options)
  tracks = []
  options[:tracks].each do |track|
    next if track.volume.zero?  # skip muted tracks

    if SoxEffect.needed?(track)
      file = Tempfile.new 'effect'
      SoxEffect.new(track, file.path).run
      tracks << SoxMixer::Track.new(file, 'wav')
    else
      file = File.open track.filename, 'r'
      tracks << SoxMixer::Track.new(file, 'mp3')
    end
  end

  temp = Tempfile.new 'mixer'
  SoxMixer.new(tracks, temp.path).run
  FFmpeg.new(temp.path, output).run
  # ... waveform, callback, cleanup
end

The mixer command itself is straightforward — sox -m (mix mode) combines all input files into one output:

class SoxMixer < Executable
  def to_cmd
    mix = '-m' if @tracklist.size > 1
    "sox #{mix} " << @tracklist.map { |track|
      "-t #{track.format} -v 1.0 #{track.file.path}"
    }.join(' ') << " -t wav #@output"
  end
end

The FFmpeg wrapper¶

The MP3 encoding settings are configured globally:

class FFmpeg < Executable
  def to_cmd
    "ffmpeg -i #@input -ar #{MP3_FREQ} -ac #{MP3_CHANNELS} #@quality #@overwrite -f #@format #@output"
  end
end

Default settings: 44.1 kHz sample rate, stereo, 128 kbps CBR with optional VBR at quality 5. The Wavepass subclass reuses the same FFmpeg wrapper but outputs WAV instead of MP3 — used to convert FLV recordings from Red5 to a format that sox can work with.

Red5: the RTMP bridge¶

The Red5 instance is the simplest piece of the puzzle — a standard Red5 deployment configured for RTMP on port 1935 with 16-64 threads. When the Flash client records from the microphone, the audio streams via NetStream.publish() to Red5, which writes it to disk as an FLV file. The uploader then picks it up, converts to WAV, and runs it through the same analyze → normalize → encode pipeline.

Red5 is completely stateless — it doesn’t know about users, tracks, or songs. It just records audio streams to files. All the coordination happens between the Flash client and the Rails apps.

The waveform¶

Every encoded track gets a companion waveform PNG, generated by wav2png:

Adelao::Waveform.generate(input, output.sub('.mp3', '.png'), :width => length * 10)

Width is length * 10 — roughly 10 pixels per second of audio. A 3-minute track gets a ~1800px wide waveform. The Flash multitrack editor loads these PNGs and displays them behind the playhead, giving users a visual map of the audio.

Deployment¶

The uploader runs on the same server as the main app, deployed via Capistrano. The BackgrounDRb daemon starts via nohup script/backgroundrb start and listens on 127.0.0.1:22222. The audio spool directory is symlinked from shared/audio into the Rails public path.

The git story¶

The uploader repo has 120 commits from April 2008 to October 2010. Andrea Franz built the initial skeleton — the controller structure, Capistrano deployment, basic BackgrounDRb integration. I came in a month later and built the encoding pipeline, the sox integration, the normalization logic, and the service callbacks.

The busiest day was June 30, 2008 with 17 commits — that was the day the mixing pipeline came together. The whoops chain from May 27 (“whoops.”, “whoops. [2]”) was me debugging the first working upload. And the Flash upload hack from July 22 deserves a special mention — Flash uploads in Internet Explorer require an HTML response, not XML, so the controller had to detect the browser and switch formats. Good times.

That’s the complete Myousica stack — from the Rails platform to the Flash multitrack to this audio pipeline. Three years of work, four services, ~2,000 commits across five people. The code is all on GitHub.

Repositories:

• mewsic/mewsic-uploader — audio processing service
• mewsic/mewsic-red5 — Red5 media server instance
