April 20, 2014 · 3 min read

Taking Back Your Network Stack from Cisco AnyConnect

• networking
• macos
• security
• open-source

Cisco AnyConnect is the kind of software that makes you question whether the people who wrote it have ever actually used a computer outside of a corporate cubicle. You install it, you connect to the VPN, and suddenly all your traffic is being funneled through your employer’s network. Your personal browsing, your Spotify, your SSH sessions to your own servers – everything. And there is no setting to change it. It is by design. The sysadmins at HQ decided what is best for you, and what is best for you is a full tunnel with zero user control.

The problem

AnyConnect installs a kernel extension (yes, a kext) and a persistent daemon that takes ownership of your routing table the moment you connect. It sets itself as the default gateway for everything, ignoring any routes you had before. It also hijacks DNS, pointing all resolution through the corporate servers. You cannot even resolve your home NAS by hostname anymore.

The official Cisco answer to “can I do split tunneling?” is “ask your administrator.” Great.

The fix: OpenConnect + split tunnel + split DNS

OpenConnect is an open-source client that speaks the AnyConnect protocol. It connects to the same VPN gateway, but it gives you control over what happens after the tunnel is up.

I wrote a set of scripts – openconnect-macos – that replace the entire AnyConnect client with three files:

• vpn.conf – OpenConnect connection config, plus a list of INTERNAL_ROUTES that should go through the VPN:

  INTERNAL_ROUTES="10.0.0.0/8 172.16.0.0/12 192.168.0.0/16"


• net.macos.sh – a custom vpnc-script that only routes the specified subnets through the tunnel, and sets up split DNS via macOS scutil:

  # Register corporate domains for split DNS resolution
  scutil <<EOF
  d.init
  d.add SupplementalMatchDomains * corp.example.com internal.example.com
  d.add ServerAddresses * 10.0.0.53
  set State:/Network/Service/org.openconnect/DNS
  EOF


  Only queries for corp.example.com go to the corporate DNS. Everything else hits your normal resolver. No more leaking your browsing habits to the corporate proxy.

• vpn.sh – the runner script, configured for passwordless sudo via a sudoers entry.

The result: corporate resources are reachable, everything else takes its normal path. Your Spotify keeps streaming. Your SSH sessions stay alive. Your packets, your rules.

It works on Linux too, with a slightly different network script.

Fair warning: employers force full-tunnel VPNs for a reason — it’s part of their security posture. By bypassing it, you may be violating your company’s security policy, your employment contract, or both. You are responsible for your own actions. I am absolutely, categorically not responsible if you get fired, audited, or escorted out of the building by IT security. You’ve been warned.

The code: github.com/vjt/openconnect-macos
