Remote LUKS? Pfft. Here is how to SSH-Unlock a ZFS-Encrypted FreeBSD Root (The Hard Way)

If you run FreeBSD like I do, on a remote server with full disk encryption (ZFS on GELI), you know the panic of rebooting. You are always at the mercy of a KVM-over-IP or a VNC connection from the browser, to insert the root filesystem password at the kernel prompt.

Nevertheless, if you (like me) run a system with kern.securelevel > 0, then installing a new libc means rebooting single user and installing the updates over said KVM or VNC connection, that is not ergonomic to say the least.

The standard solution is usually a pre-boot SSH environment. On Linux, dropbear-initramfs makes this trivial. On FreeBSD? You are building a custom mfsroot (memory file system) from scratch.

Most guides out there suggest using a static shell script as init. This works, but it’s miserable. You lose job control (no Ctrl+C), you have no proper TTY, and good luck if you need to debug network issues interactively.

I didn’t want a hacky script. I wanted a real environment. I wanted init, getty, login, PAM authentication, and a ZFS chroot for maintenance - to install updates.

Here is how I built a robust remote unlocker for FreeBSD.

The Problem with /bin/sh as Init

The naive approach is to compile a tiny ramdisk, shove a static sh binary in it, and tell the loader to run it as PID 1.

# This creates nightmares
cat > /sbin/init <<EOF
#!/bin/sh
/sbin/dropbear
exec /bin/sh
EOF

Why does this fail?

1. No job control: /bin/sh as PID 1 doesn’t handle terminal sequences that trigger signals like SIGINT. If you run a command that hangs, you can’t Ctrl+C out of it. You are stuck.

2. No switch-root (aka reroot). FreeBSD’s way of switching the current root is built on the RB_REROOT flag of the reboot() system call, but its use is restricted to PID 1. So reboot(8) sends a signal to init(8) to shutdown or reroot the system. If your init is a shell script, the system hangs instead of pivoting.

The Architecture

To solve this, we need to replicate the FreeBSD boot process in miniature. My mfsroot contains:

1. Real /sbin/init: The actual FreeBSD init binary handles signal propagation and process reaping.
2. Real /usr/libexec/getty: Sets up the TTY properly so job control works.
3. Real /usr/bin/login + PAM: Authenticates against the real root password hash copied from the host.
4. ZFS Tools: To import the pool and chroot into the main system for emergency updates without fully booting.

The mkunlock Script

I wrote a script to automate the generation of this image. It grabs necessary binaries (including dynamic libraries via ldd), configures a minimal PAM stack, and preps the RC scripts.

Here is the logic flow:

1. Build Phase: Creates a staging directory structure.
2. Library Harvesting: Copies dropbear, geli, init, login, and their shared object dependencies (libc, libpam, libgeom, etc.).
3. Configuration: Generates a minimal /etc/rc, /etc/ttys, and /etc/gettytab.

The “Magic” Reroot

The hardest part was getting the kernel to switch from the Ramdisk to the ZFS root after unlocking. The trick is using reboot -r (reroot) but ensuring the environment is clean.

We need to:

1. Set kenv vfs.root.mountfrom="zfs:tank/ROOT".
2. Unmount the physical boot partition.
3. Remount root read-only (mount -ur /).
4. Run reroot via /sbin/reboot -r.

Upsides

The resulting environment is beautiful. When the server boots, it loads the 30MB ramdisk and configures the network.

I SSH in and get a shell, and from the host console I can also log on with a password of the system, or another one if we don’t want to copy over the target system’s password hash to the unencrypted ramdisk.

Once inside, I have three custom tools:

• unlock.sh: Attaches the GELI provider using the keyfile and password.
• enter.sh: Imports the ZFS pool to a temporary mountpoint and chroots into it. This allows me to run freebsd-update (or nowadays pkg upgrade as I have pkgbase) or fix configs in Single User mode equivalence - without booting the full system.
• boot.sh: Performs the clean pivot to the decrypted OS.

Downsides

There are of course a few downsides - as nothing comes for free!

• If the system reboots without your intervention, it’ll end up exposing a dropbear on some port. I’m not using the standard one, but it is reachable nevertheless.
• If you use the same root password in the main system and in the rescue environment, you are exposing the hash in the unencrypted RAM disk.
• When the system is updated, you should re-run mkunlock to ensure the userland is in sync with the kernel.

The Code

If you want to stop praying every time you type reboot, grab the script from my repo.

https://github.com/vjt/mfsroot-geli-dropbear

Download it, run it, and it’ll create a /boot/mfsroot.gz file. You can then enable it at boot by editing your loader.conf:

# Load modules
geom_md_load="YES"
zfs_load="YES"

# Load initrd
mfs_load="YES"
mfs_type="md_image"
mfs_name="/boot/mfsroot"

vfs.root.mountfrom="ufs:/dev/md0"

Ensure to not have a geom_eli_load="YES" line in your loader.conf otherwise the kernel will detect your encrypted root and ask you to insert its password!

FreeBSD is powerful, but sometimes you have to scratch your own itch!
