Setting up an Arlo camera on Home Assistant should look like this:

1. You install the integration from HACS.
2. You type your Arlo email and password.
3. Your phone buzzes. You tap Approve in the Arlo app.
4. You click Submit in Home Assistant.
5. You’re in.

That’s the entire flow. It is the same trusted-browser flow that my.arlo.com runs in your laptop — the integration just routes one push through your phone, captures the 14-day trust cookie Arlo issues, and goes silent.

You’ll need that push approval again only when the cookie expires. The integration persists it across restarts and re-uses it on every wake-up. In the common case, you authenticate once and then never see another auth dialog.

The project lives at github.com/vjt/ha-eisenberg. I called it Eisenberg, after Arlo Eisenberg the skater. The name was an act of weakness. Move on.

What you get out of the box¶

• A camera entity with on-demand snapshots, motion thumbnails, and live RTSPS streaming. Sub-second lag in HLS. The dashboard tile keeps an image even when the camera is disarmed (Arlo refuses cloud snapshots in standby) by caching the last good frame on disk.
• Motion binary sensors, both the generic kind and AI-classified person / vehicle / animal sensors that auto-reset.
• A security-mode select — armAway, armHome, standby — that you can drive from any automation. Tie it to your alarm panel, your person.* state, a time schedule, anything.
• A siren switch, battery and signal-strength sensors, base-station connectivity.
• An eisenberg.snapshot service for dashboard buttons or motion-driven automations. Fails loudly if the camera is in standby instead of silently no-op’ing, because that’s the kind of thing you only debug at 1 AM.
• Optional rolling archival of motion clips, thumbnails and stream keyframes to a media_dirs location, with user-configurable retention (default 14 days).

Every motion event also fires an eisenberg_media event on HA’s bus with the AI categories, the content URL, the thumbnail URL, the duration, the timestamp. Hook automations onto it.

How it works¶

The integration is event-driven. There is no polling loop. Arlo pushes its state changes — motion, AI classification, snapshot URL, mode change, base-station heartbeat — over an MQTT firehose, and a single coordinator distributes those to entities the moment they arrive. REST is used only for the things that actually need a request/response: starting a stream, setting a mode, firing a snapshot, the initial device discovery.

Auth¶

The first login does the full handshake: POST /api/auth with the password (base64-encoded) yields a short-lived token. That token then drives POST /api/getFactorId to ask Arlo whether this browser is already trusted. If it is, POST /api/startAuth completes the trip silently and you’re authenticated. If not, you get a push — exactly one — that the user approves on their phone, then a single POST /api/finishAuth confirms. Arlo’s response includes a 14-day trust cookie which we persist into the Home Assistant config entry. Every subsequent restart re-uses that cookie and login completes silently in three round trips.

Crucially: the form-driven flow makes one HTTP call per user click in the HA dialog. There’s no polling task hammering finishAuth while the user fumbles for their phone — Arlo rate-limits that endpoint hard, and a tight retry loop is the fastest way to lock yourself out for hours.

The token expires after roughly two hours; the coordinator checks every 30 minutes and refreshes silently at the 60-minute mark, which keeps a comfortable headroom against expiry.

MQTT¶

Arlo’s event firehose is plain MQTT 3.1.1 over a WebSocket. The integration implements that protocol directly on top of the same aiohttp WebSocket session it uses for REST — no second TCP stack, no separate library to keep alive across reconnects. The MQTT codec is a small module that does packet framing for the half-dozen control packets that matter (CONNECT, SUBSCRIBE, PUBLISH, PINGREQ) and drops everything else.

Each subscribed topic has a typed handler. Camera state lands in cameras/+/is, motion events in feed/live, snapshot URLs in fullFrameSnapshotAvailable, mode changes in automation/activeMode/is, and so on. The coordinator routes each frame to the right handler, parses the payload into a Pydantic model, and updates entity state. If a payload doesn’t match the expected shape, it’s logged at WARNING — that discipline surfaced three event types Arlo had quietly started emitting that nobody had noticed before.

Streaming¶

Arlo serves live streams over RTSP-on-port-443-with-TLS, which is technically RTSPS. The API tells you rtsp://. Don’t believe it: rewrite the URL to rtsps:// before handing it to Home Assistant’s stream worker, and force TCP transport (UDP can’t traverse TLS). Then add three ffmpeg flags — fflags=nobuffer, flags=low_delay, use_wallclock_as_timestamps — and HLS lag drops from ~30 seconds to under one. I checked.

The browser User-Agent gets RTSP from Arlo’s startStream endpoint. A mobile UA gets DASH instead, which is harder to bend to HA’s stream component, so the integration sends a Chrome UA for everything except this one call.

Mode setting¶

Arming the camera lives in Arlo’s v3 location automation API: PUT /hmsweb/automation/v3/activeMode?locationId=…&revision=N with body {"mode": "armAway"}. The revision counter is the optimistic-concurrency token — bump it on every read, echo it on every write. If a parallel client (the Arlo mobile app, an automation) bumps the counter behind us, the PUT fails; we re-fetch the live revision and retry once.

Image persistence¶

The dashboard tile would otherwise blank out every time the camera is disarmed (no live snapshots) or every restart (no in-memory cache). Both problems get solved the same way: every snapshot, motion thumbnail, or stream-end keyframe goes both to the in-memory cache and to disk under the configured media_dirs location. On boot, the coordinator scans that location for the newest image per camera and seeds the cache from disk. A retention prune (configurable, default 14 days) sweeps old files on every health-check tick.

Why I built it¶

I have one Arlo camera. It’s cloud-only by design and there was nothing I could do about that, but I wanted the part between my Home Assistant and Arlo’s cloud to be small enough that I could read it end to end. Native asyncio, types at every boundary, no scraping tricks, no library I didn’t want to inherit. Roughly 1500 lines of Python in the integration plus the client library, all of it on PyPI under MIT, and that was the whole goal.

Get it¶

HACS → Custom repositories → https://github.com/vjt/ha-eisenberg

Or click the badge below — it deep-links into your Home Assistant instance with the repo pre-filled:

Source is MIT. The client library is pyeisenberg on PyPI.

---
