mwan3 Failover Without the Hung Connections

• openwrt
• mwan3
• networking
• conntrack
• nftables
• projects
• ai-generated
• open-source

TL;DR: mwan3 reroutes new flows when an uplink dies. Existing flows stay pinned to the dead path — conntrack remembers, the firewall flow offload keeps shovelling packets along it, and long-lived TCP sockets linger until their application notices and reconnects. The native flush_conntrack option is a global nuke. The fix is a fifteen-line /etc/mwan3.user that does a selective conntrack flush by mwan3 mark on disconnected events only.

How I Got Here¶

After migrating Jeeves — my GL.iNet GL-X3000, the 5G router that handles the backup uplink so I don’t lose another meeting — to vanilla OpenWrt 25.12, I went back to running my failover drills on the gateway: pull the fiber, watch what happens. Pull the 5G, watch what happens. Repeat.

The scenario was always the same one I’d been observing for months. mwan3 itself did its job — pings to 1.1.1.1 recovered in seconds, the routing tables flipped to the surviving member, new sessions came up on the right interface — but every long-lived TCP connection that had been established before the failover just sat there, dead. They came back eventually. On a wall-clock measured in minutes, usually governed by the application layer’s own timeouts.

I’d known about this for a while and had been working around it. Embarrassingly long, in fact — I’d just never carved out the time to actually dig in and figure out where the slowness was coming from. The new round of drills made the lingering connections impossible to keep filing under “later”.

First on the casualty list, on my home network: the Technitium DNS server that forwards every outbound query in the house over DNS-over-TLS to upstream resolvers (so my ISP doesn’t get to see the names I’m asking for — UDP/53 in cleartext is not a hill I’m dying on). Its long-lived TLS sockets to those resolvers hung. The Home Assistant WebSocket to its mobile companion app hung. Anything with a persistent TCP connection from before the failover sat there, mute, while new connections worked fine.

That’s not failover. That’s a coin flip.

What’s Actually Happening¶

My default gateway, golem, is a GL.iNet GL-MT6000 running vanilla OpenWrt. It runs mwan3 across two members:

When fiber dies, mwan3:

1. Updates the routing tables so new connections go via 5G.
2. Walks away.

What it does not do: anything to the conntrack entries created while fiber was alive. Those entries still carry ct mark = 0x100, the fiber mark.

That’s already a problem on its own. But on this router I make it worse on purpose: I run with software flow offload enabled in fw4 (OpenWrt’s nftables-based firewall). Flow offload is a kernel fast-path: once conntrack has classified a flow as ESTABLISHED, subsequent packets bypass the regular netfilter chains and ride a dedicated forwarding shortcut. Important on an ARM router pushing a gigabit fiber line.

The shortcut is keyed on the flow’s tuple plus output device. After fiber dies, the offloaded entries for fiber-marked flows still point at eth1. From golem’s point of view, eth1’s link to the ISP modem is perfectly healthy — mwan3 detected the failure via upstream ping timeouts, not via a local link-down event. So the router keeps emitting packets onto the dead path. Where they actually die depends on what failed (the modem’s PPPoE session, the optical fiber upstream, the ISP’s gateway — pick one). The modem will probably emit ICMP Destination Unreachable for the first few packets it can’t forward, and golem will dutifully un-SNAT and forward those errors back to the LAN client — but TCP, per RFC 5461, treats ICMP unreachables on an established connection as soft errors and ignores them while retransmitting, rather than tearing the socket down on the first one. The client kernel keeps the socket open. The application waits.

Eventually whatever app-level timeout that connection has fires — DoT clients carry short ones, WebSockets pong-timeout in tens of seconds, SSH depends on whatever ServerAliveInterval you set, if any — and the application closes the dead socket, opens a new one, and recovers over the alive uplink.

The kernel’s own tcp_keepalive_time is set to 7200 seconds by default, so without any app-level timeout at all you’d be looking at the two-hour fallback. In practice nothing on my network is patient enough to wait for that, and the actual recovery measures in single-digit to low-double-digit minutes. Still way too long for something that’s supposed to be transparent.

Things I Considered That Didn’t Work¶

I came at this from four angles before landing on the right one. The reasons each one fails are interesting in themselves.

ss -K on the clients. Kill the offending sockets from the client side, let the application reconnect. Wrong layer: I’d have to deploy a hook on every device that ever holds a long-lived socket through this gateway, and keep doing so as the device list grows.

Forge a spoofed RST from the gateway. Have golem inject a TCP RST into each affected flow with the right tuple, so the client kernel marks the socket ECONNRESET and the application reconnects. RFC 5961 requires the RST sequence number to be inside the receiver’s window — and conntrack does not expose the current sequence numbers (-o extended and -o xml both omit them). Out-of-window RSTs are silently discarded. Dead end without a packet capture per flow.

A permanent nft reject with tcp reset rule on a wrong-mark exit. Stand a firewall rule in the forward chain that fires whenever a packet still tries to leave with one uplink’s mark but the device it is exiting is the other uplink’s. The rule is permanent in the ruleset; it only matches when conntrack’s idea of where the flow should go has diverged from the routing table’s, which is exactly the post-failover symptom. Correct in spirit, but the moment a flow is in the offload table it no longer traverses the forward chain at all — that’s literally what offload does: skip the chains. The rule never sees the packet unless the offload entry is invalidated first. Which only happens on… a conntrack flush. Circular.

mwan3’s native flush_conntrack option. Looked promising right up until I read the source: it’s echo f > /proc/net/nf_conntrack, a global flush of every flow on the router. Wireguard, Tailscale, LAN-to-LAN forwarding, the surviving WAN’s established connections, all of it. Every time mwan3 emits any configured event. Massive collateral damage for a problem that needs surgery.

The Fix¶

What was needed: flush only the conntrack entries marked with the dead uplink’s mwan3 mark, only on disconnected events. Conntrack already supports this — conntrack -D -m <mark>/<mask> deletes by mark. mwan3 already labels every flow with its member’s mark. The two just needed to meet.

/etc/mwan3.user runs on every mwan3 hotplug event:

. /lib/functions.sh
. /lib/mwan3/mwan3.sh
config_load mwan3

flush_dead_uplink() {
    local id mark
    mwan3_get_iface_id id "$1"
    [ -n "$id" ] && [ "$id" != "0" ] || return 0
    mark=$((id << 8))
    conntrack -D -m "${mark}/0x3F00" 2>/dev/null
    logger -t mwan3-flush "selective conntrack flush iface=$1 mark=$(printf 0x%x $mark)"
}

case "$ACTION" in
    disconnected) flush_dead_uplink "$INTERFACE" ;;
esac

One thing that almost shot my foot off: config_load mwan3 is mandatory. mwan3_get_iface_id reads from a runtime table that is only populated after the mwan3 config has been walked. Skip the load, the lookup returns empty, the mark computes to 0x000, and conntrack -D -m 0/0x3F00 matches every unmarked flow on the router — local-origin traffic, LAN-to-LAN, the lot. The [ -n "$id" ] && [ "$id" != "0" ] line is the seatbelt that refuses to fire on an empty or zero id.

What Happens Now¶

When fiber dies:

1. mwan3track misses pings, emits disconnected wan.
2. mwan3 updates the routing tables: new flows mark 0x200 (5G).
3. /etc/mwan3.user runs.
4. Conntrack entries with mark & 0x3F00 == 0x100 are deleted, which also drops their fw4 flow offload entries. Subsequent packets for those flows go back to traversing the regular netfilter path.
5. The next packet on a previously-pinned socket reaches golem without a matching conntrack entry. Provided nf_conntrack_tcp_loose is on — the default on OpenWrt — the kernel accepts the mid-stream segment as a fresh ESTABLISHED conntrack entry, routes it via the now-current default route (5G), and the masquerade rule on the 5G WAN rewrites its source IP and port to the 5G WAN address.
6. The remote receives a TCP segment from a tuple it has never seen before.

The remote’s behaviour is now the dominant variable.

Polite remote (most CDNs, Google, Cloudflare DoT): unsolicited segment for an unknown tuple → RST back → the client kernel marks the socket ECONNRESET → the application reconnects within an RTT. This is what 99% of the internet does.

Silent-drop remote (some enterprise firewalls, some BGP anycast frontends): swallows the segment, no reply. The client retransmits per tcp_retries2 until the kernel gives up (~15 minutes by default) or the application’s own timeout fires first. For DoT, Technitium has short app-level timeouts and reissues queries on a fresh socket within seconds. The bound is set by the application, not by the kernel. If a particular long-lived service of yours happens to live behind a silent-drop remote and has a long app timeout, the escalation is to turn flow offload off and add the nft RST rule on the wrong-mark exit — but I have not needed to.

That’s enough. Failover now actually fails over. Pings recover, and sockets recover, on the same timescale.

The whole thing is fifteen lines of shell hooked to one hotplug event. The mwan3 author already did the hard part — every flow is marked, every event is fired, every primitive is sitting there waiting to be composed. All that was missing was the surgical flush. Reliability is not a setting. Reliability is something you build.

Both /etc/mwan3.user and the mwan-ct operator helper (list, count, top-talkers, inspect-offload, manual flush by uplink) live in vjt/mwan3-selective-flush on GitHub. Drop them in, smoke-test with the recipe in the README, done.
